SP608E 8CH Output Bluetooth Addressable LED Controller Trigger

LED Controller Features SP608E is a 8CH Bluetooth Addressable LED controller, offers the convenience of control through both a mobile APP and an RF remote. 1. With 8 different lighting effects to choose from, it’s suitable for a variety of occasions and can meet the diverse needs of customers. 2. It supports common single-wire LED driver ICs available on the market. 3. Built-in music and non-music effects offer multi-parameter adjustability. 4. The grouping control function allows for any combination control of 8 channels. 5. Customize trigger effect parameters with the built-in trigger function. 6. A wide range working voltage of DC5V-24V and protection against reverse power supply connection provide added peace of mind. 7. The power down save setting parameter function ensures your settings are preserved. Bluetooth Addressable Controller Parameters APP: BanlanX Input Voltage: DC5~24V Working Current: 20mA~130mA Remote control distance: 30M Output Pixel: 2048 Max Output Signal: SPI Control Method: Bluetooth Dimensions: L100*W60*H48(mm)/3.94*2.36*1.88” Working temp.: -20°C~60°C Certification: CE, RoHS Weight(G.W.): 70g Bluetooth APP Functions – The SP608E offers the convenience of control through a mobile APP, compatible with both IOS and Android systems. – Apple phones require IOS 10.0 or higher, while Android phones require Android 4.4 or higher. – To find the app, simply search for “BanlanX” in the App Store or Google Play, or scan the QR code to download and install. How to use BanlanX APP for SP608E Addressable LED Controller? To add a device, open the app and tap the button located in the top right corner of the home page. Once the device has been successfully added, select it to access the control page. Renaming the controller is easy – simply click on the button in the upper right corner. The SP608E supports output for 8 different signals. For individual control, select Channel 1 – Channel 8 to access the corresponding page, or choose all channels for uniform control of all 8 channels. SP608E SPI Controller Connection Diagram For Pixel LED Light Strip
